78-88 G-Body Complete FULL Frame Wrap – DXF Files

Save time and money by cutting the kit out locally. You can cut this kit out using 2 sheets of 4’x8′ (3/16″ or 1/4″ thick) steel sheets of metal. These are the DXF files that we use to cut the kits out, these are not the metal pieces. This is only a .DXF file to be used in a CAD program. It must be turned into G-Code by your CNC metal cutter. It can be cut using Plasma, Water Jet or Laser.

What you get:

– DXF files nested in a 4×8 format.
– DXF files nested in a in 4×4 format. (We use 4×4 sheets because they are easier to handle and we do not lose much area during nesting.)
– Individual DXF files for each part.
– After you cut the kit locally, you will end up with 66 pieces.
– DXF files will all be sorted and named appropriately within 1 zip file.
